FVD article number / Reference number:
FVD20798803

FVD Brombacher Motorsport Oil Pan 986/987.1/996/997.1 X51 Baffle + Extra Capacity

Name: FVD Brombacher Motorsport Oil Pan 986/987.1/996/997.1 X51 Baffle + Extra Capacity
Brand: FVD
SKU: FVD20798803
Price: 498.61 EUR
Availability: InStock

€498.61

Prices include 19% value added tax, excl. shipping.
Depending on the delivery address, value added tax may vary.*

1–2 working days (the dates given are based on estimates and on standard national and international shipping with a standard-sized parcel and do not represent a guaranteed delivery time).

Insured shipping | Free shipping from 911€.

Product description

Product Description

Background:
Porsche M97.01 wet-sump engines (986, 987.1, 996, and 997) are susceptible to oil starvation and oil aeration during sustained high-G cornering. In aggressive turns, oil in the shallow factory oil pan can move away from the pickup, or air can enter the pickup, causing pressure drops and aerated oil. This reduces oil pump efficiency and, if left unaddressed, can lead to rapid oil-pressure loss and catastrophic engine damage.

Even on street setups with Porsche-approved N-spec tires, spirited driving on mountain roads, canyon roads, or winding backroads can trigger these issues. The risk increases significantly with high-grip R-compound tires, which generate greater lateral forces and can expose the pickup precisely when the engine demands maximum oil pressure.

Aerated oil is especially dangerous because it compresses under load and cannot maintain stable hydraulic pressure. This reduces oil pump efficiency, can cause pump cavitation, and may result in brief or sustained oil-pressure loss even while the pump is operating normally. Drivers may notice momentary oil-pressure fluctuations under high load—an early warning that the factory oil pan and pickup are being overwhelmed.

Mechanical solutions provide the most effective protection. Increasing oil capacity, improving baffling with anX51-style oil pan, or using a deeper oil pan helps control oil movement, keeps the pickup submerged, and minimizes aeration and pressure fluctuations during spirited street driving and track use.

Usage:
Since 2012, the FVD-Brombacher Motorsport Oil Pan has set the benchmark for Porsche M97 oil-control upgrades, combining precision engineering with proven reliability for both street and track use. Its true bolt-on design installs without modifying the factory engine, adding retrofit baffles, or relying on oversized spacers or sump guards that reduce ground clearance. For drivers who enjoy mountain roads, canyon roads, or club track days, this straightforward design preserves vehicle integrity while minimizing the potential for installation errors.

The pan increases oil capacity by 0.6 L (approximately ¾ qt) while incorporating integrated X51-style baffling. Together, these features help prevent oil starvation and oil aeration during high-grip, high-G cornering, providing a consistent oil supply under demanding driving conditions.

Serviceability is equally important. Because the pan bolts directly in place of the factory unit, it can be removed easily for future maintenance without disconnecting additional plumbing or removing skid plates. High-temperature polymer trap doors offer several advantages over traditional metal designs. They flex under load without fatiguing, resist vibration, and provide smooth, low-friction operation. Metal trap doors can bind or seize under heat and sustained lateral forces, while FVD's polymer design delivers reliable, consistent performance over the long term.

Precision-machined in Germany to exacting standards, every oil pan features integrated cooling fins and a matched pickup extension to maintain a consistent oil supply during extreme cornering. The FVD-Brombacher Motorsport Oil Panis a purpose-built upgrade engineered to improve lubrication system performance, protect your engine, and provide confidence in both daily driving and high-performance applications.

Quick Highlights:

True Bolt-On Design – Installs without modifications.
Balanced Performance and Ground Clearance – Integrated X51-style baffling and an additional 0.6 L (approximately ¾ qt) of oil capacity help protect against oil starvation during high-G driving while maintaining street-friendly ground clearance.
Reliable Polymer Trap Doors – Flex under load, resist vibration, and operate smoothly without the binding associated with metal designs.
Optimized Oil Control – Keeps oil at the pickup to reduce starvation and aeration.
Precision German Manufacturing – Integrated cooling fins and a matched pickup extension provide reliable lubrication under demanding conditions.
Proven Performance Without Added Complexity – Effective oil control in a simple, bolt-on package.

Additional Recommendation:

Complete Oil Pan with Installatiob Kit and Magnetic Draun plug:FVD 207 988 03KIT
Oil Pan Installation Kit:FVD20798801INS
Magnetic Drain Plug:FVD10717601

Fitment & Quantity:

M97 Engine Family
986, 987.1, 996, and 997

About FVD-Brombacher:
Since 1984, FVD-Brombacher has sourced and manufactured Porsche components through elite OEM suppliers, specialized German manufacturers, and respected performance engineering partners. Unlike many aftermarket brands that support multiple vehicle platforms, FVD focuses exclusively on Porsche. This singular commitment allows us to develop and refine components with a level of precision, integration, and vehicle-specific engineering rarely matched in the aftermarket.

Based in Germany, we serve Porsche enthusiasts worldwide while managing logistics in-house to ensure fast shipping, dependable service, and efficient customs processing. Our mission is simple: preserve Porsche heritage while enhancing performance through components engineered for precision, durability, and driving enjoyment.

Compatibility & Liability Notice:
Vehicle compatibility must be verified before installation, and the product must be installed correctly. FVD-Brombacher assumes no liability for damage resulting from improper installation or use outside the intended application.
